30-Year, 160 mph Wind Warranty

• - ANSI/SPRI GT-1 Tested to comply with International Building Code
• - FM Approved for wind uplift protection
• - Provided in 12'-0" lengths.
• - Larger sizes accommodate the drainage of large roof areas with minimal downspouts.
• - No external brackets or wind straps translates to faster lead time because no post-paint is required.
• - Pre-assemble components on the roof to increase safety and ease of handling during installation.
• - Rauch Alignment Bar is a unique tool that ensures the proper placement of lower mounting hanger and eliminates measuring and chalking.
• - Pre-punched holes provide quicker installation and ensure correct fastener placement and spacing.
• - Adapts easily to optional waterproofing applications with gutter apron, drip edge, or termination bar.
• - Factory fabricated miters and accessories provide a cleaner, more aesthetically pleasing appearance. This eliminates the need for field fabrication, providing time and labor savings.
• - Available in variety of colors and finishes.

• Versions: Box
• Materials: 22 ga. galv. steel and .050", or .063" aluminum
• Standard Sizes:  Available in the following standard sizes.
  • (Front Height | Bottom Width | Back Height)
    - 8" | 8" | 9"
    - 9" | 9" | 10"
    - 10" | 10" | 11"
    - 11" | 11" | 12"
    - 12" | 12" | 13"
    - 13" | 13" | 14"
    - 14" | 14" | 15"
  •
  • NOTE: Front Height and Bottom Width will be the same and Back Height will be 1" more than Front Height
